Breaking through conventional material limitations! Realize strong adhesion!
(FPR/EPDM is also applicable)
Application scope:
Rubber, plastic, metal, ceramic
TOP1 Japanese quick drying adhesive brand
81.2%
Japan's quick-drying glue retail market share
2023/1/1-2024/12/31 Data from Japan INTAGE Company
Hand Taobao Scan Code
200Series 400Series 732F | 500Series | 600Series | 800Series | 900Series | GEL-10 | |
Basic monomer (liquid state) | ||||||
Appearance (*) | Colorless or light yellow liquid | |||||
Proportion(d204) | 1.050 | 0.978 | 1.004 | 1.069 | 1.090 | 1.090 |
Boiling point(℃/667Pa) | 60-62 | 78-80 | 68 | 200 | —— | 60-62 |
Flash point(C)(tag closed type) | 83 | 95 | 77 | 112 | 83 | 83 |
Randian(C) | 485 | 410 | 463 | 330 | 330 | 485 |
Freezing point(℃) | -29.6 | -2.1 | -18.7 | Below-20 | Below-20 | Below-20 |
Polymer (solid state) | ||||||
Appearance (*) | Colorless or light yellow liquid | |||||
Specific gravity (d) | 1.248 | 1.125 | 1.156 | 1.168 | 1.200 | 1.290 |
Hardness (Shore D, 23C) | 90 | 80 | 80 | 60 | 30 | 90 |
Linear expansion coefficient x10-4 | 1.1 | 1.3 | 1.5 | 1.0 | 1.1 | 1.1 |
Heat deformation temperature (C-Vicat method) | 145 | 110 | 110 | 60 | —— | 145 |
Glass transition temperature(℃) | 140 | 125 | 115 | 80 | 80 | 140 |
Dielectric loss tangent(10MC,10℃) | 0.07 | 0.07 | 0.07 | 0.07 | 0.07 | 0.07 |
Dielectric constant(10MC,10C) | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 |
Breakdown voltage(KV/0.1mm,23°C) | 14 | 14 | 14 | 14 | 14 | 14 |
Volume insulation resistance(Ωcm,30C) | 1014 | 1014 | 1014 | 1014 | 1014 | 1014 |
Solvents | Acetone, dimethylformamide, methyl sulfoxide |
